Yaesu FT-65

• Frequency Coverage : TX/RX : 136-174MHz Rx only : FM radio (76 - 107.95MHz) AM (118 - 135.99MHz • Modulation : F3E(16K0F3E / 11K0F3E / RX only WFM,AM) • Frequency stability : ±2.5ppm • Power supply requirement : 7.4V (Battery) • Current drain (Approx.) : 1500mA TX / 300mA receive at Max audio output 80mA squelched • Usable temperature range : －20～ +60℃(-4～140°F) • Channel step : 2.5, 5, 6.25, 10, 12.5, 20, 25, 30 dan 50 KHz • Dimensions : 11,8 x 5,9 x 3,8 cm (With battery pack) • Weight : approx.230g inclusive of battery pack and antenna TRANSMITTER • Output Power (Approx) : Approx. 5W / 2W / 1W • Frequency Deviation : ±5kHz / ±2.5kHz • Spurious emission : Less than －27dBm RECEIVER • Receiver System : Direct conversion • Sensitivity (12dB SINAD Wide/Narrow) : Wide -12dBu / Narrow -9dBu • Adjacent Channel Selectivity : Wide More than 65dB Narrow More than 60dB • Audio output power : 1W (10% distortion)

• Frequency range: [TX] 144 - 148MHz, 420 - 450MHz [RX] 136 - 174MHz, 400 - 480MHz [ TX/RX] 144 - 146MHz, 430 - 440MHz • Modulation : F3E (FM) • Frequency step :2.5, 5, 6.25, 8.33, 10, 12.5, 20, 25, 30 and 50KHz • Memory channel :200 memory channels in total • Antenna impedance :50ohm unbalanced • Frequency stability :+/- 2.5ppm • Supply voltage :DC 7.4V (Battery) • Current consumption :1400mA TX / 300mA receive at Max audio output 70mA squelched • Battery-save ON :average 27mA • Temperature range :Unit -20 ~ +55digC (-4 ~ 131digF) • Battery packs : -10digC to +45digC (+14 to +113digF) • Dimensions :5,9W x 9,8H x 3,5D cm w/o projection • Weight :approx.227g or 8.01oz inclusive of battery pack and antenna Transmitter • Power Output: (Approx.value) : Approx.5 / 2.5 / 1W • Modulation : Variable reactance FM • Spurious emission : -60dB or less • Max. deviation : FM : +/- 5KHz NFM: +/- 2.5KHz Receiver • System : Direct-conversion • Sensitivity : Wide -12dBu / Narrow -9dBu • Intermediate frequency : 1st IF 38.85MHz, 2nd IF 450 KHz • Selectivity : -6dB : Wide 12kHz /Narrow 10kHz or more -60dB :Wide 30kHz / Narrow 24kHz or less • AF output :1W (10% distortion)

GENERAL • Frequency Range : RX : 136 - 174 MHz : 400 - 480 MHz TX : 144 -148 (146 MHz) 136 - 174 (Asia) FM Broadcast : 65-108 MHz • Channel Steps : 5/6,25/10/12,5/15/20/25/50 KHz • Frequency Stability : ±5ppm + 14˚F to + 140˚F |- 10˚C to + 60˚C) • Emmision Type : F2D, F3E, • Antenna Impedance : 50 Ohms • Current Cosumption : 190 mA (Recive) 200mW Output 95 mA (Standby,Saver Off) 23 mA (Standby Saver On • Operating temperature : -4˚F to +14˚F |- 20˚C to +60˚C • Case Size : 5,2cm x 100,4cm x 3,1cm W/O Knob and anntena • Supply Voltage : Nominal 7,4V DC, Negative Ground TRANSMITTER • RF Power Output : 5W (High)/ 2,5W(Middle)/ 0,5W(Low) @7,4V • Modulation Type : Variable Reactance • Maximum Deviation : ±5.0KHz • Spurious Emmision : At Least 60dB down {@High and Middle Power} At least 40dB down {@Low power} • Microphone Impedance : 2k Ohms Receiver • Circuit Type : Direct-Conversion • Sensivity : 0,2V for 12dB SINAD {140 – 150MHz, NFM} 0,2V for 12dB SINAD {420 – 470MHz, NFM} * FT-65 only • Selectvity : 12KHz / 35KHz (-6dB /-60dB) • AF Output : MAX Power 1W@16Ohms, 0,8W @ 16 Ohms for 10% THD

• Frequency Range : RX : 136 - 174 MHz : 400 - 480 MHz TX : 144 -148 (146 MHz) 136 - 174 (Asia) 430 - 450 (440 MHz) 400 - 480 (Asia) FM Broadcast : 65-108 MHz • Channel Steps : 5/10/12,5/15/20//25/50/100 KHz • Frequency Stability : ±2.5ppm + 14˚F to + 140˚F |- 10˚C to + 60˚C) • Emmision Type : F2D, F3E, F2A • Antenna Impedance : 50 Ohms • Current Cosumption : 190 mA (Recive) 200mW Output 95 mA (Standby,Saver Off) 23 mA (Standby Saver On • Operating temperature : -4˚F to +14˚F |- 20˚C to +60˚C • Case Size : 5,2cm x 9cm x 3cm TRANSMITTER • RF Power Output : 5W (High)/ 2,5W(Middle)/ 0,5W(Low) @7,4V with SBR-28LI • Modulation Type : Variable Reactance • Maximum Deviation : ±5.0KHz • Spurious Emmision : At Least 60dB down {@High and Middle Power} At least 50dB down {@Low power} • Microphone Impedance : 2k Ohms Receiver • Circuit Type : Direct-Conversion • Sensivity : 0,2V for 12dB SINAD {140 – 150MHz, NFM} 0,2V for 12dB SINAD {420 – 470MHz, NFM} * FT-4x only • Selectvity : 12KHz / 35KHz (-6dB /-60dB) • AF Output : MAX Power 1W@16Ohms, 0,8W @ 16 Ohms for 10% THD
